Product name: Magnetostrictive Linear Level Sensors
The product model:KYDM-F Series

application:KYDM Magnetostrictive liquid level transducer provides high accurate measurement of liquids level sensor designed for huge tank or vessels. It can be tailored to special length and mounting requirements for flooded evaporator.


  • Details
  • Specifications
  • Product Diagram

Description

For central air environment, KangYu developed a special solution that successfully solved the problem of electromagnetic interference to achieve precision measurements for flooded evaporator refrigerant level, improving the entire unit of cooling efficiency.

Features

Characteristics1: Double-shield structure, effectively

against electromagnetic interference.

The sensor uses double-shielded structure, which have passed the CE certification, complies with the following EMC standards.



EN61000-6-1:2007
EN61000-6-3:2007
EN61000-3-2:2006
EN61000-3-3:2008



Characteristics2: replace the sensor without removing the refrigerant, and reducing Repairs costs.

The sensor uses double tube design, also based on the bypass pipe is more narrow space, using core pulling structure (the pipe can be pulled together in the warehouse along with electronic sensors), when the sensor needs to be replaced, no refrigerant removed, and greatly reducing maintenance time and avoid refrigerant waste. So the customers do not need to send someone to the scene, its own end-users have to replace the sensor, greatly reducing maintenance costs.



Characteristics3: easy to install, saving installation costs.

Flooded evaporator air conditioning unit level measurement generally have a bypass pipe, liquid level sensor is mounted on the bypass pipe, Kang Yu-magnetic-foot 2-inch NPT thread design for thread (also according to customer requirements), directly onto the inner thread of the bypass pipe, without external flange and reduce customer's manufacturing costs.



In addition also the following features:

◆High accuracy to meet the high requirements metering of tank level measurement occasions;

◆Stable performance, without affect of temperature and pressure changes of gas and liquid inside the tank;

◆Various output options to meet a variety of collection system requirements;

◆Intrinsic Safety Certification:ExiaIIBT5,to adapt to a variety of safe applications;

◆Modbus, which can measure various parameters of liquid level, interface, temperature;

◆Various anti-corrosive structure, to meet a wide range of oil, chlorine and other corrosive measurement environment;

◆Easy installation, no maintenance.

Specifications:



Range

2001000mm

Operating voltage

+24VDC±10% ;±15VDC±10%

Outputs

420mADC

Non-linearity

<±0.05% F.S.

Temperature coefficient

±0.007%F.S./℃

Cable

integral connector

Operating temperature

-40+85

Storage temperature

-40+100

Sealing

IP65

Pressure

4MpaMax.

Interface thread

G1



     Note: The F.S. is short for Full Scale.



Application Overview:

KYDM Magnetostrictive liquid level transducer provides high accurate measurement of liquids level sensor designed for huge tank or vessels. It can be tailored to special length and mounting requirements for flooded evaporator.

Product Dimension:



【G.W】:1.5kg

【N.W】:1.3kg
